TE Connectivity L001016-01 Ultra-Wide Band Antenna and Evaluation Board

Introduction

The TE Connectivity L001016-01 is an ultra-wideband (UWB) antenna and evaluation board designed for testing and developing UWB wireless sensing, positioning, and access-control solutions. It supports UWB channels 9 and 10, operating from 7737.6 MHz to 8736 MHz.

Part Description

The L001016-01 combines a UWB antenna with an evaluation-board format, helping engineers evaluate antenna behavior and integrate UWB connectivity into prototypes. Its wide operating range supports channel 9 and channel 10 UWB implementations.

Key RF characteristics include:

• Frequency coverage from 7737.6 MHz to 8736 MHz
• Support for UWB channels 9 and 10
• More than 120° angle-of-arrival coverage
• Greater than 60% average efficiency
• Maximum VSWR below 2:1
• Peak gain of 3.4 dBi

The antenna is suited to designs that require short-range, high-precision wireless ranging, direction finding, presence sensing, or secure proximity detection.

Applications

Potential applications for the L001016-01 include:

• Ultra-wideband radar systems
• Obstacle detection equipment
• Collision-avoidance systems
• Real-time location systems (RTLS)
• Indoor navigation devices
• Secure access and authentication systems
• Asset tracking tags and anchors
• Proximity detection devices
• Direction-finding systems
• UWB development and antenna evaluation platforms

Industries

Possible industries using this UWB antenna and evaluation board include:

• Industrial automation
• Warehousing and logistics
• Robotics
• Automotive and transportation
• Smart-building technology
• Security and access control
• Healthcare equipment
• Consumer electronics
• Retail and asset management
• Research and product development

Usage Ideas

1. Indoor Asset Locator
   Build an RTLS prototype that uses UWB anchors and mobile tags to identify the position of tools, containers, or equipment within a warehouse.

2. Robot Obstacle Detection Platform
   Integrate the evaluation board into a mobile robotics test system for evaluating UWB-based ranging and collision-avoidance functions.

3. Secure Door Access Demonstrator
   Create a proximity-based access-control prototype that verifies the distance and direction of an authorized UWB-enabled credential before unlocking a door.

Conclusion

The TE Connectivity L001016-01 Ultra-Wide Band Antenna and Evaluation Board provides a practical platform for UWB channel 9 and 10 development. With broad angle-of-arrival coverage, efficient RF performance, low VSWR, and 3.4 dBi peak gain, it is well suited for positioning, navigation, radar, sensing, obstacle detection, and secure-access prototypes.
